Embedded Bootable USB Flash Drives up to 8 GB

Embedded Bootable USB Flash Drives

Fast Boot for Image File: Embedded USB Flash Drives

Available up to 8 GB

General

C-1's Embedded USB Flash Disk is the ideal data storage device in any USB capable systems supporting compatible 256MB to 8GB with highest data transfer rate, supports dual channel interleave access. It fits easily into any platform with an embedded USB connector, and can be secured firmly into place for enhanced ruggedness.

It can work with any operating system that supports USB mass storage class devices, such as Windows XP embedded and Linux. With advanced SLC NAND flash technology, the Embedded USB Flash Disk is superior in its data storage characteristics with industry’s highest performance and data protection in hardware

Features:

•    Compatible with USB2.O/1. 1

•    Equipped with SLC (Single Level Cell) NAND Flash technology

•    Capacity: 256MB 8GB

•    Highest data transfer rate supporting dual channel interleave access

•    Dual-Channel and interleave mode support to achieve best performance

•    Write-Protect switch for security

•    Support for major embedded OS, including Windows XPe and Linux

EUSB Specifications

*Capacity*	256MB ~ 8GB
*Dimension*	37.8mm x 26.65mm x 7.7mm
*Weight*	about 5 g
*USB Interface*	USB2.0/ 1.1
*Embedded O/S supports*	Windows XP Embedded and Linux
*Operating Systems*	Windows 98/ME/2000/XP; Linux kernel 2.4 and above
*Temperature*	Operating: 0 deg C ~ 70 deg C Non-Operation: -40 deg C ~ + 85 deg C
*System Performance (Dual-Channel)*	Read: 30MB/sec (Max.) Write: 18MB/sec (Max.)
*Power Requirement*	DC 5V ±10%
*Data Retention*	10 years
*Connector Durability*	10,000 times
*Reliability*	1,000,000 program/erase cycles
*Order Information*	UDUXXX-HR1 (Horizontal in right side with 2.54 pitch) UDUXXX-HR2 (Horizontal in right side with 2.0 pitch) UDUXXX-HL1 (Horizontal in Leff side with 2.54 pitch) UDUXXX-HL2 (Horizontal in Leff side with 2.0 pitch)

Ordering Information
5V Horizontal EUSB Flash Drives:

We offer rightwards and leftwards versions. Please check here for specifications, pitch size and orientation.

Part Number Horizontal, Right Side, 2.54 pitch.	Part Number Horizontal, Right Side, 2.0 pitch.	Part Number Horizontal, Left Side, 2.54 pitch.	Part Number Horizontal, Left Side, 2.0 pitch.	Price
UDU256-HR1	UDU256-HR2	UDU256-HL1	UDU256-HL2	$67
UDU512-HR1	UDU512-HR2	UDU512-HL1	UDU512-HL2	$80
UDU01G-HR1	UDU01G-HR2	UDU01G-HL1	UDU01G-HL2	$102
UDU02G-HR1	UDU02G-HR1	UDU02G-HL1	UDU02G-HL1	$149
UDU04G-HR1	UDU04G-HR1	UDU04G-HL1	UDU04G-HL1	$209
UDU08G-HR1	UDU08G-HR1	UDU08G-HL1	UDU08G-HL1	Call

PRICE. Please click here to inquire volume pricing and lead time.

WARRANTY & SUPPORT. Tech support from manufacturer and PSI. 1 year warranty.

TO ORDER OR INQUIRE. Please e-mail us at psi@psism.com or call (301) 572-2168 to order and/or inquire. We accept Visa, MasterCard, Discover and American Express as well as government and university POs.

Please click here to order or view our ordering information page.
