Industrial Grade Solid-State Memory Cards for Industrial Applications
PSI distributes all kind of industrial-grade PCMCIA cards, readers, flash drives and other storage & I/O solutions for industrial PCs, embedded computing needs as well as for industrial applications. For an overview of the nomenclature used in the NAND flash storages, please read here. (Courtesy of APRO Co., Ltd.)
The following table gives the compatibility matrix of the solid-state memory cards and the known industrial devices. PSI supplies both commercial-grade and industrial-grade ruggedized cards with commercial and extended operating temperature options.
Why do you need industrial-grade memory cards instead of their cheaper consumer-grade counterparts?
Industrial-grade cards are made to sustain severe operating conditions such as high impact, continuous vibration, low and/or high operating temperature. These cards are durable and can last intensive reads/writes. Certain cards are even made to be moisture-resistant. Consumer-grade memory cards are not as durable. For most of the industrial applications which normally require intensive I/O cycles, the consumer-grade cards tend to fail prematurely.
| Category
I : Type I Linear Flash Cards (industrial grade cards available, click here) |
ABB AC450 (IMC004FLSA); Alcatel PBX system 4400 (4MB, II); Alesis music keyboard/synthesizer QS 8.2 (5V, 8MB); Apollo GX-50 GPS (C,D); Apple E-mate 300 (AMD, II+, series 100); Newtons 100, 120 & 130 (AMD, II, II+), MessagePad (2000, 2100, 3000) ; Digital Ocean Tarpon & Seahorse; BP Micro programmer (AMD 12MB); Chrysler DRB III scanner (II);Domino A-400 CP printers(II); Ford/Hickok NGS (New Generation Star) tester ( I); GE Fanuc CNC Series (FN5008); GM/Vetronix Tech2 scanner (series II, D, Value 100); HP 100 & 200 LX (5V); Honeywell CU10481 (PM24276); Intermec Janus 2010 (see remark below), 2020 (5v), EC-301 Printer (iMC002FLSC); Konica/Minolta Copiers DI620, DI520, DI550, CF2002, CF2001, CF 3102, CF3502 (AMD); Korg PA80 (8/16MB); Kyrocera printers; Mavowatt 45 (AMD); Mitel SX200EL Phone system (D, 4MB); Motorola Envoy 150 (2 MB) & Marco; Nissan Console II tester (D, 32MB); Northstar GPS-60 (I, 1MB); Olympus D-1000 voice recorder (mini-flash IFM008A); Ricoh 3800 copier (D); RisoGraph ink duplicator(II, 4MB); Scitex 5120 printer (32MB, D); Sharp Zaurus ZR5000, 5700 & 5800 & Expertpad (up to 24MB); Siemens NCU (4MB[II], 8MB [Value 100]), TXP (II); Timemark Delta 3 (FLSC), Lamda (II) traffic controllers; Telco Access 6024 CMM (1MB, series I), 6025 CMM (2MB, 5V); Toshiba Tec Printer B472 (I); Woodward controllers; Zebra barcode printers, 140XiIII, etc.(D); Zoll M-series Defibrillator (II); etc. & Cisco, Nortel, Xyplex, Lucent, Ascend, Nokia & 3COM Router Memories |
| Category
II : ATA Flash Memory Cards (industrial grade cards available, click here) |
Acura
MDX Navigation; AG Leader PFadvantage yield monitor;
AT&T/Avaya Phone systems;
Bernina
Sewing
& Embroidery Machine
Artista
200E; Case IH Ver4.5 yield monitor;
Casio
Cassiopeia A-10 , A-11 & A-11 Plus, Z-7000,
Casio Japan Cassiopeia
A-50; Compaq
Companion-HPC C120, C120+, C140, C-series 810, 2010 &
2015; Entek
1200, 2500 Vibration
Analyzer; Flir (Infomatrics)
MP290 thermoCam (Sandisk); GE
Fanuc
CNC Series 18-B, 18-C, 18i-A, 20-A, 21-B, 21i-A (Sandisk); Geomation 2380;
HP OmniGo 100/200 & 200/300/320/360/620/700 LX; Hitachi
HPC &
HPW10E (up to 20 MB); Heidelberg
Printmaster 74; Honeywell
Multi-Trend; IBM TP 700T; Janus (Intermec) 2020D, 5020;
Leica GS50 GPS (Sandisk); LG Electronics GP 20M/40M &
Phenom HPC; Lucent CBX500 and
GX550; Merit
Game machine; NCR
7450 POS;
NEC MobilePro 200,
400, 450, 700, 770, 780, 800; Nortel
PBX 11C; Novatel
Wireless C-O-N-T-A-C-T;
Oxford FD4; Prolinear
HPC; Respironics
SmartMonitor 2; Roland AR-3000, MS-1 Sampler
(Sandisk); Sharp Mobilon HC-4000, 4100,
4500; Zaurus MI504, 506; Toshiba
T200; Trimble
TSC1 GPS Logger, Tharo
printer; Vera Logic EPM32
Cheetah PC ; etc. Also,
Acura MDX Navigation; Epson EHT-40, EHT-400C; Fujitsu Stylist 500; Lucent CBX500 and GX550; Toshiba Dynapad T200; Alpine (Acqra) GPS Navigation system; etc. |
| Category
III : Type I PCMCIA SRAM Cards (industrial grade cards available, click here) |
Advantest R3465, U-3641 analyzers (2MB); AG Leader yield monitors (w/o 2KB); Alesis DM Pro, S4 and QS Series music keyboard/ synthesizer; ; Amstrad NC100, NC200; Apple E-mate 300 , Newton 100, 120, 130 & MessagePads (with 2KB); Applied/PE Bio system PCR9700; BSS FDS-388; CSI 2120 analyzer (8MB); Case IH yield monitor (w/o 2KB); Casio Zoomer Z7000; Chroma video generator 2329; Clavia Nord Lead Synthesizers; Compaq HS-D40, J40, J50 & Z50 controllers; DataTaker 600/605; Demag 1430; Dipstick 2000 floor profiler; Dranetz PP4300; Emerson CSI 2120-2 vibration analyzer, MPC5 controller; Emulator Ultra Proteus synthesizer; Ensoniq KT & MR Series; Entek IRD Vibration Analyzer DP1500; FATO CL408 Printer; Fluke Hydra 2635A; Fujitsu Poet; GE Fanuc CNC Series (need attribute) 15-B, 16-B, 16-C, 16i-A, 18-B, 18-C, 18i-A, 20-A, 21-B, 21i-A, Power Mate H (PM-H), PM-1, Motion Mate MCS700; HP 95/100/200/700 LX, 1000CX & OmniGo 100/120 & 8935 series Analyzer; Interek (RRD)1250; Intermec Janus 2010 **(see below), 2020, 5020; IRD Datapac 1500; Janus 2010/2020; Kantrox MUX; Korg 01/Wfd; Kyrocera-Mita printers; LaserAtlanta Rangefinder; Leica TC1100, TCA-1600, TCR 1102 (2MB); Magic Cap DataRover; Markem printers; Micro-Trak & Satloc Yield Monitors (w/o 2KB); Midas XL4; Motorola Envoy 150 (2MB) & Marco (2MB) (with attribute); Nikon DTM720, 750 survey instruments; Omron CVM1B PLC (2KB); Pfaff sewing machine; Rockwell Automation/Entek DP1250 (2MB), DP1500; Roland AR-3000, MS-1; Sharp Mobilon HC-4000, 4100, 4500, PDA 3100, Zaurus ZR5000, 5700, 5800 (with attribute, 2MB), Norand; Sony Magic Link (with 2KB); Satloc GPS system (w/o 2KB); Schlumberger Advance Meter Readers; Schneider TSX, Quantum and Micro Processors; STA DP2624; Sumitomo SH100A molding machine; TekLynx PrintPad 2000; Telxon PTC1140; Topcon FS & GTS data collectors; Toyo TM150 molding machine; Two Technology PCL-50 terminal; Trimble NT200D; Uson Testra 1100; Vandorn Demag 1430 Ton, Pathfinder 5000; Videx Omniwand; Wavetak data collector, etc. |
| Category
IV : CompactFlash Cards (industrial grade cards available, click here) |
Casio
Cassiopeia A-20, A-50, A-51, BE-300, E-10, E-11, E-15, E-100, E-115, E-125, PA2400; Compaq
Aero models, iPAQ 3635/H3135; Everex
Freestyle; IBM PalmPad 100, WorkPad Z50; HP 320/360/620 LX, Jornada
420/428/430/525/540/545/548/ 620/660/680/720/820;
Hitachi HPC (CE2.0); Intermec
Janus 5020; LG Electronics
Phenom;
NEC
MobilePro 700, 780,800 ; OTC Genisys
scanner; Palmax PD-300; Philips
Ninos;
Psion Series 5, 7 (3.3V);
Samsung InfoGear;
Sharp
Zaurus MI504, 506, 5060C; Toshiba
E570, 740; Uniden
Unipro
PC100/100A; Vadem Clio, etc.
Also,
Casio Cassiopeia E100, E105; Compaq 2930A, Aero 8000; HP 620LX, Jornada 430SE, 680/690, 820; IBM Z50; Minolta Dimage 7; Psion Netbook, Series 7; Sharp Zaurus MI504, 506; Vadem Clio C1050; etc. Please click here to check more compatibility. |
| Category
V : MMC Card & Secure Disk (SD) Cards (industrial grade cards available, click here) |
MMC: Casio Cassiopeia EM500; EM500UB; Diamond Rio
500, etc.; Fluke
DSP-4300; Toshiba E310;
etc. SD card: Compaq iPaq 3850, 3870; Palm i705, m125, m500, m505, etc.; Toshiba E310; etc. |
1. Mini IDE Flash Disk Modules
Please click here for pricing and more info. They are your great choices for the rugged PCs, industrial PCs and embedded PCs.
2. Industrial Grade 1.8", 2.5" & 3.5" IDE Flash Drives
Please click here for pricing and more info. These flash drives are faster, ruggedized and can operate in an extended temperature range. They are your great choices for the rugged PCs, industrial PCs and embedded PCs.
3. Industrial Grade ATA Flash Cards
Please click here for pricing and other info. These cards are ruggedized and can operate in an extended temperature range. up to 16GB.
4. Industrial Grade Compact Flash Cards
Please click here for pricing and other info. These cards are ruggedized and can operate in an extended temperature range. Up to 8GB.
5. Industrial PCMCIA Linear Flash Cards
We supply Intel i-series linear flash cards for routers, industrial data collection devices, etc. Please click here for more info. We also supply Centennial/Smart commercial grade and industrial grade flash cards. For a complete list of Centennial/Smart memory cards, please click here.
6. Industrial PCMCIA SRAM Cards
PSI supplies commercial-grade PCMCIA SRAM cards with replaceable or rechargeable battery for palmtops, industrial data collection devices, etc. Industrial-grade SRAM cards are also supplied for extended temperature applications. You may find more info about the industrial SRAM cards by clicking here.
For Centennial/Smart SRAM
specifications, please click here. For
a complete list of commercial grade and industrial grade SRAM cards, please click
here.
7. Sandisk & APRO SATA SSD Flash Storage for Military and Industrial Applications, new!
Please click here for more info. about these Sandisk SATA 5000 flash drives. and here for APRO industrial-grade SATA flash drives.
7. Sandisk UATA 5000 SSD Flash Storage for Military and Industrial Applications, new!
For Sandisk UATA 5000 2.5" flash drives, please click here.
For Sandisk UATA 5000 1.8" flash drives, please click here.
9. Rugged USB Portable Flash Drive for Industrial Applications, new!
Please click here to find it out.
10. USB Bootable Flash Drives for IPC, SBC and Embedded Systems, new!
Please click here for information.
11. Industrial Micro SATA Flash Drives , new!
Please click here for APRO Micro SATA flash drives..
12. CF-to-IDE and CF-to-SATA Adapters for IPC, SBC and Embedded Systems, new!
Try to add one or two bootable type II CF slot to your embedded system? Please click here for more info of the CF-to-IDE adapters and here for CF-to-SATA adapters..
13. PC-104 Internal PCMCIA Drives for Industrial PCs
High performance of PC-104 bus interface, 16-bit or 32-bit cardbus stackable module. Stack up to 4 units. Please click here for more info.
14. Memory Card Drives (Readers/Writers) for Industrial PC Cards
Please click here for more info.
15. Extreme Temperature Hard Drives (HDDs) for Mission-Critical Applications, new!
Please click here for the extreme temperature hard drives, (-20 deg C ~ +85 deg C).
16. Enterprise Network Storage Solutions, new!
Please click here for Qlogic, NSI/Double-Take Software & Intel/Brocade network storage solutions, and Hammer Storage network drives, Fujitsu switches, Western Digital hard drives & JDS Uniphase transceivers, etc.
17. Low Power & Ruggedized I/O Cards/Adapters
Please click here for CF and PCMCIA serial I/O (RS-232) cards and USB serial I/O adapters.
18. Zeus High-Speed SSD Flash Storage for Military and Industrial Applications
Please click here for more info. about these Zeus flash drives.
PRICE.
Please click here
to inquire volume pricing and lead time.
WARRANTY &
SUPPORT. Tech support
from manufacturer and PSI. Warranties are covered by
manufacturers. For tech support
and/or RMA, please go to http://www.psism.com/support.htm.
TO ORDER OR INQUIRE. Please click here to place an online order or send e-mail inquiry to sales@psism.com or call (301) 572-2168. We accept Visa, MasterCard, Discover and American Express as well as government and university POs. International orders may be conditionally accepted. Please click here to order or view our ordering information page.
